Features
• Hot pluggable QSFP28 form factor
• Four independent full-duplex channels
• Supports 103.125Gbps aggregate bit rates (up to 25.78125 Gbps per wavelength)
• Transmission distance of 2km on SMF
• 4x25Gbps 1310nm DFB transmitter
• 4x25Gbps electrical interface
• Power Consumption < 3.5W
• Single 3.3V power supply
• CAUI-4 high speed electrical interface
• Single MPO-12 receptacle
• Built-in digital diagnostic functions
• Compliant with IEEE 802.3bm 100GBASE PSM4
• Compliant with RoHS-6 (lead-free)
• Operating Case Temperature:
Commercial temperature range(COM): 0 to 70°C
Applications
• 100G Ethernet Links
• 25G Breakout Applications
• Infiniband QDR and DDR Interconnects
• Datacenter and Enterprise Networking
• Other Optical Links
