Features
• Hot-pluggable SFP+ footprint
• Supports 10GBASE-T Operation in Host System
• Transmission distance up to 30m with Category 6a/7 Cable
• Compact RJ-45 Connector Assembly
• Auto-negotiates with other 10GBase-T PHYs
• Low power consumption (2.5W Max at 30m)
• I2C 2-Wire Interface for Serial ID and PHY Register Access
• Auto-sense MDI/MDIX
• Single 3.3V power supply
• Compliant with SFP+ MSA specification SFF-8431 and SFF-8432
• Compliant with RoHS-6 (lead-free)
• Operating Case Temperature:
Commercial temperature range(COM): 0 to 70°C
Applications
• 10G Ethernet Data Center Intra-Rack and Inter-Rack links
• 10GBASE-T IEEE 802.3an
• 10GBASE-T IEEE 802.3ab
• 10GBASE-T IEEE 802.3u
• Other Links
